HB-DJ825 Linear Actuator(Free 3D Prints)
Speed: 6–15 mm/s,
Customizable travel itinerary: 30–1000 mm,
Voltage: 12V, 24V, 36V, 48V DC brushed motors,
Operating conditions: IP66, duty cycle 20%,
Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
Position feedback: Hall sensors, reed switches, limit signals,
Low noise: approximately 45 dB.
Keywords:
HB-DJ825 Linear Actuator(Free 3D Prints)
- Product overview
- Parameter
- 3D drawing
-
- Commodity name: HB-DJ825 Linear Actuator(Free 3D Prints)
- Commodity ID: 1051781310692810752
Load: 1000 N–2000 N, <br/> Speed: 6–15 mm/s, <br/> Customizable travel itinerary: 30–1000 mm, <br/> Voltage: 12V, 24V, 36V, 48V DC brushed motors, <br/> Operating conditions: IP66, duty cycle 20%, <br/> Operating temperature: low temperature -10°C or -40°C, high temperature 65°C. <br/> Position feedback: Hall sensors, reed switches, limit signals, <br/> Low noise: approximately 45 dB.
- Model: HB-DJ825,
- Load: 1000 N–2000 N,
- Speed: 6–15 mm/s,
- Customizable travel itinerary: 30–1000 mm,
- Voltage: 12V, 24V, 36V, 48V DC brushed motors,
- Operating conditions: IP66, duty cycle 20%,
- Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
- Position feedback: Hall sensors, reed switches, limit signals,
- Low noise: approximately 45 dB.
Key words:- HB-DJ825
- high temperature
- DC
- 30–1
- 000 mm
- model
- load
- position
- 6–15 mm
- low temperature
- electric actuator
- 12 V
- 24 V
- low noise
- silent
-
-
