HB-DJ802 Electric Linear Actuator（Free 3D Prints）
Model: HB-DJ802; Rated Load: 3,200–12,000 N (optional); No-Load Speed: 6.5–38 mm/s; Input Voltage: 12 V, 24 V, 36 V, or 48 V DC (optional); Custom Stroke: Recommended ≤ 1,000 mm; Duty Cycle: 25%; Operating Temperature: –40°C to 65°C; Signal Feedback: Optional limit signals, Hall sensors, potentiometers, and magnetic switches.
A. Optional Parameters
Rated Load: 800–5,000 N, optional
No-Load Speed: 7–40 mm/s, optional
Input Voltage: 12 V or 24 V DC, optional
Custom Stroke Length: Recommended ≤ 1,200 mm
Duty Cycle: 20% or 35%, optional; under normal ambient temperature and full-load conditions, continuous operation is recommended to not exceed 2 minutes
Lead Screw Type: Standard trapezoidal lead screw
Motor Type: Standard brushed DC motor
Signal Feedback: Optional limit‑switch signals and Hall sensors available
b. Standard Protection Features
Built‑in bidirectional limit switches that automatically cut power when the actuator reaches its fully extended or fully retracted position
Operating Temperature: -10°C to 65°C (optional ultra‑low‑temperature protection down to -40°C)
IP66 dust‑ and water‑proof rating, suitable for outdoor applications
Aluminum alloy body, stainless steel piston rod, and corrosion‑resistant zinc‑nickel plated connection ends
A. Optional Parameters
Rated Load: 1000–3000 N, optional
No-Load Speed: 4–22 mm/s, optional
Input Voltage: 12 V or 24 V DC, optional
Custom Stroke Length: Recommended ≤ 300 mm
Duty Cycle: 15%; under normal ambient temperature and full-load conditions, continuous operation is recommended to not exceed 2 minutes
Lead Screw Type: Standard trapezoidal lead screw
Motor Type: Standard brushed DC motor
Signal Feedback: Permanent Magnet DC Motor
Signal Feedback: Optional dual Hall pulse feedback or switch position signal
Operating Temperature: -25°C to 65°C
b. Standard Protection:
External Overcurrent Protection Limit Switch
A. Optional Parameters
Rated Load: ≤2000N
No-Load Speed: 3.4–30 mm/s
Input Voltage: 12 V or 24 V DC, selectable
Custom Stroke Length: Recommended ≤1000 mm
Duty Cycle: 15%; under full‑load conditions at room temperature, continuous operation is recommended to not exceed 2 minutes
Lead Screw Type: Trapezoidal Lead Screw
Motor Type: Standard DC Brushed Motor; DC Brushless Motor available as an option
Signal Feedback: Hall Sensor
b. Standard Protection
Built‑in bidirectional limit switches that automatically cut power when the actuator is fully extended or fully retracted
Operating Temperature: -10°C to 55°C Protection Rating:
IP65 Dust‑ and Water‑Proof
Aluminum Alloy Housing with a Corrosion Resistance Rating of Nss 480h
A. Optional Parameters Rated Load: 250–1,200 N (optional) No-Load Speed: 4–20 mm/s (optional) Input Voltage: 12 V or 24 V DC (optional) Custom Stroke Length: Recommended ≤ 1,000 mm Duty Cycle: 20%; under normal ambient temperature and full-load conditions, continuous operation is recommended for no more than 2 minutes Lead Screw Type: Standard trapezoidal lead screw Motor Type: Standard brushed DC motor b. Standard Protection Built-in bidirectional limit switches that automatically cut off power when the actuator is fully extended or fully retracted Operating Temperature: -10°C to 65°C (optional – optional ultra-low‑temperature protection available down to -40°C) IP66 dust‑ and water‑proof rating, suitable for outdoor use Aluminum alloy body and piston rod, with corrosion‑resistant zinc‑nickel plated connection ends
a. Optional parameters Rated load: 500–5000 N No-load speed: 6-80 mm/s Input voltage: 12, 24, 36, 48V DC Custom Itinerary: Recommended ≤1000MM Duty cycle: 25%. Under full-load conditions at room temperature, continuous operation is recommended. No longer than 2 minutes. Screw types: Trapezoidal screw, ball screw Motor Type: Standard DC Brush Motor Signal feedback: Optional limit signals, Hall sensors, and reed switches. b. Built-in bidirectional limit switches that automatically cut off power when fully extended or retracted. Standard protection Operating temperature: -40℃~65℃ Protection rating: IP66 dustproof and waterproof Aluminum alloy body, stainless steel inner tube, and corrosion-resistant galvanized nickel connecting terminals.
HB-DJ830G Linear Actuator(Free 3D Prints)
Rated load: 1,200–12,000 N, optional;
No-load speed: 6.7–66.7 mm/s;
Input voltage: 12 V, 24 V, 36 V, or 48 V DC, selectable;
Customized travel itinerary: recommended ≤1000 mm;
Duty cycle: 20%–30%;
Operating temperature: -10°C to 65°C (optional ultra-low-temperature protection down to -40°C);
Signal Feedback: Optional configurations include limit switches, Hall sensors, potentiometers, magnetic switches, and manual adjustment of overcurrent protection.
No-load speed: 6.7–66.7 mm/s;
Input voltage: 12 V, 24 V, 36 V, or 48 V DC, selectable;
Customized travel itinerary: recommended ≤1000 mm;
Duty cycle: 20%–30%;
Operating temperature: -10°C to 65°C (optional ultra-low-temperature protection down to -40°C);
Signal Feedback: Optional configurations include limit switches, Hall sensors, potentiometers, magnetic switches, and manual adjustment of overcurrent protection.
HB-DJ805H Linear Actuator(Free 3D prints)
Stroke: 50-1000mm, Max Dynamic Load: 17,000N, Max Static Load: 20,000N, Speed: 5 – 35 mm/s, IP66 Protection, Voltage: 12, 24, 36. 48V DC
HB-DJ806 Linear Actuator(Free 3D Prints)
Load: 50 N–1200 N,
Speed: 5.5–80 mm/s,
Customizable travel itinerary: 30–1000 mm,
Voltage: 12V, 24V, 36V, 48V DC brushed motors,
Operating conditions: IP66, duty cycle 25%,
Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
Position feedback: potentiometer, reed switch, limit signal.
Speed: 5.5–80 mm/s,
Customizable travel itinerary: 30–1000 mm,
Voltage: 12V, 24V, 36V, 48V DC brushed motors,
Operating conditions: IP66, duty cycle 25%,
Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
Position feedback: potentiometer, reed switch, limit signal.
HB-DJ809 Linear Actuator(Free 3D Prints)
Load: 200 N–2000 N,
Speed: 5–55 mm/s,
Customizable travel itinerary: 30–1000 mm,
Voltage: 12V, 24V, 36V, 48V DC brushed motors,
Operating conditions: IP66, duty cycle 25%,
Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
Position feedback: Hall sensors, potentiometers, reed switches, and limit signals.
Speed: 5–55 mm/s,
Customizable travel itinerary: 30–1000 mm,
Voltage: 12V, 24V, 36V, 48V DC brushed motors,
Operating conditions: IP66, duty cycle 25%,
Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
Position feedback: Hall sensors, potentiometers, reed switches, and limit signals.
HB-DJ830 Linear Actuator(Free 3D Prints)
Force: 1000N-4000N,
Speed: 5.5-35mm/s,
Stroke: 50-1000mm,
Voltage: 12, 24, 36, 48V brushed DC,
Working Environment: IP65, duty cycle 25%,
Operation Temp.: low -10 or -40℃, high 65℃,
Position Feedback: Hall effect sensor, reed switches, or end-stop signal.
HB-DJ830P Linear Actuator (Free 3D Prints)
Load: 2000 N–7000 N,
Speed: 5.5–35 mm/s,
Customizable travel itinerary: 50–1000 mm,
Voltage: 12V, 24V, 36V, 48V DC brushed motors,
Operating conditions: IP65, duty cycle 25%,
Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
Position feedback: Hall sensors, reed switches, limit signals,
Supports both electric and manual operation.
Speed: 5.5–35 mm/s,
Customizable travel itinerary: 50–1000 mm,
Voltage: 12V, 24V, 36V, 48V DC brushed motors,
Operating conditions: IP65, duty cycle 25%,
Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
Position feedback: Hall sensors, reed switches, limit signals,
Supports both electric and manual operation.
HB-DJ808Linear Actuator(Free 3D Prints)
Load: 2000 N–7000 N,
Speed: 5.5–35 mm/s,
Customizable travel itinerary: 50–1000 mm,
Voltage: 12V, 24V, 36V, 48V DC brushed motors,
Operating conditions: IP65, duty cycle 25%,
Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
Position feedback: Hall sensors, potentiometers, reed switches, and limit switches.
Speed: 5.5–35 mm/s,
Customizable travel itinerary: 50–1000 mm,
Voltage: 12V, 24V, 36V, 48V DC brushed motors,
Operating conditions: IP65, duty cycle 25%,
Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
Position feedback: Hall sensors, potentiometers, reed switches, and limit switches.
HB-DJ805G LinearActuator（Free 3D Prints）
Load: 3,200 N–12,000 N,
Speed: 6–37 mm/s,
Customizable travel itinerary: 50–1000 mm,
Voltage: 12V, 24V, 36V, 48V DC brushed motors,
Operating conditions: IP66, duty cycle 25%,
Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
Position feedback: potentiometer, Hall sensor, limit signals,
Supports both electric and manual operation.
Speed: 6–37 mm/s,
Customizable travel itinerary: 50–1000 mm,
Voltage: 12V, 24V, 36V, 48V DC brushed motors,
Operating conditions: IP66, duty cycle 25%,
Operating temperature: low temperature -10°C or -40°C, high temperature 65°C.
Position feedback: potentiometer, Hall sensor, limit signals,
Supports both electric and manual operation.
HB-DJ850 electro-hydraulic push rod
Electro-hydraulic Actuator
Integrated hydraulic and DC motor drive system,
Voltage: 12V or 24V DC
Rated dynamic load 8000N, rated static load 15000N
Protection level: IP65
Strong impact resistance, can be used in some larger bumpy, impact environments
Supports thrust, pull, or both thrust and pull
Integrated hydraulic and DC motor drive system,
Voltage: 12V or 24V DC
Rated dynamic load 8000N, rated static load 15000N
Protection level: IP65
Strong impact resistance, can be used in some larger bumpy, impact environments
Supports thrust, pull, or both thrust and pull
Force: 1000N-4000N,
Speed: 11-69mm/s,
Stroke: 50-600mm,
Voltage: 380VAC three-phrase, 220VAC servo, 48V brushless DC, 24V brushed DC, 48V brushed DC,
Working Environment: IP55, low -10℃ to 65℃.
